Stainless Steel Close-Coupled Multistage Submersible (VN Series )
Franklin Electric - VN Series Pump for 150mm (6”) wells and larger.
Application :
- Compact close-coupled design, robust and rust resistant
- Impellers and diffusers are made of stainless steel in order to achieve durability, superior efficiency and the highest performances
- Double mechanical seal separated by an oil* chamber for maximum motor protection
- *In compliance with FDA - Food, Drug Administration - and the annex to G.U. no. 104 of 20/04/73 for oils in contact with food stuffs
- Plug-in type power cable and level control (floaters) for easy replacement
- Heavy duty over size motor shaft
- Stainless steel water proof capsule to protect the motor
- Motor cooling is guaranteed by the pumped liquid
Features :
- Capacities up to 14 m3/hr
- Heads up to 11 Bar
- Discharge outlet 1W” Rp
- Maximum working pressure 15 Bar
- Maximum immersion depth 20 m
- Maximum allowable amount of sand 50 gr/m3
- Maximum solids size up to 2 mm
- Liquid temperature range -5°C to 40°C
- Continuous operation either in vertical or horizontal position
- Motor range: 0,55kW to 3kW
- Asynchronous, Class F insulation, IP 68 protection
- 20 m of power cable type H07RN F is supplied with the standard version
